Resolution:1200 x 1200dpi (8 bits)
Number of Tones:256
Paper Size :13” x 19”, SRA3, 12” x 18”, 11” x 17”, LGL, LTR, LTRR, EXEC, Irregular Size (182mm x 182mm to 330.2mm x 487.7mm)
Paper Weight: 64 to 300g/m²
Paper Type :Thin, Plain, Heavy, Recycled, Colour, Pre-punched, Bond Paper, Transparency, Labels, Tab Paper, Coated, Texture Paper, Vellum
Print Speed :64 to 135g/m²     136 to 220g/m²            221 to 300g/m²
13” x 19”         26        23        17
SRA3              28        25        19
12” x 18”         28        24        18
11” x 17”         30        26        20
Legal:             36        33        25
A4 / Letter      60        52        40
A4R / Letter-R            46        24        31
Standard Paper Capacity :1,000 sheets x 2 Paper Cassettes (64 to 300g/m²)
Power Source: 1-phase 208V 30A
Maximum Power Consumption :Less than 6,000W
Temperature :  20 to 27°C
Humidity :30 to 70% (RH)
Punch Unit:-U1 (2H) / W1 (4H FR) / X1 (4H SE) / V1 (2/3H)
Paper Size:Punch Unit-U1
- 2 hole registration : LTR, LTR-R, 11" x 17", Legal, Exec / A3, A4. A4R, B4, B5, B5R
Punch Unit-W1
- 4 hole registration, FR: LTR, 11" x 17", A3, A4
Punch Unit-X1
- 4 hole registration, SE LTR, 11" x 17", A3, A4
Paper Weight: 64 to 300g/m²
Paper Type:Thin, Plain, Heavy, Recycled, Colour, Bond Paper, Tab Paper, Coated, Texture Paper, Vellum
Punch Unit-V1
- 2 hole registration
- Distance between hole,Legal, LTR-R
2 ¾" (70mm)
- 3 hole registration
- Distance between hole ,11” x 17”, LTR, EXEC
4 ¼" (108mm)
Duplexing :Automatic Document Feeder (DADF-R1)
Tray Capacity: 100 sheets (80g/m²)
Scanning Speed :80 sheets per minute (A4 / Letter)
Paper Size :11" x 17", Legal, Letter, Letter-R, Statement, (A3, A4, A4R, B4, B5, B5R)
Stack Bypass-A1
Paper Size :13" x 19", SRA3, 12" x 18", 11" x 17", Legal, Letter, Letter-R, Statement, (A3, A4, A4R, A5, A5R, B4, B5, B5R), Irregular size
Paper Weight: 64 to 256g/m²
Paper Capacity :100 sheets (80g/m²)
Finisher-AB1
Number of Trays:2
Tray Capacity Tray A :3,000 sheets (80g/m²)
Tray B :2,000 sheets (80g/m²)
Paper Weight :64 to 300g/m²
Paper Size :LTR / A4R, LGL / B4, 11" x 17"/A3, 450 x 320mm (SRA3), 12" x 18" / 305 x 457mm, 13" x 19"
Maximum Stapling Capacity :100 sheets (80g/m²)
Staple Position :Corner, Double Stapling
Finisher-AB1
Number of Trays :3
Tray Capacity Tray A :3,000 sheets (80g/m²)
Tray B:2,000 sheets (80g/m²)
Lower Tray (Tray C) : Unlimited
Paper Weight : 64 to 300g/m²
Paper Size :LTR / A4R, LGL/B4, 11" x 17" / A3, 450 x 320mm (SRA3), 12" x 18" / 305 x 457mmm 13" x 19"
Staple Position :Corner, Double Stapling & Saddle Stitching
Maximum Stapling Capacity Corner, Double Stapling :100 sheets (80g/m²)
Saddle Stitching :20 sheets (80g/m²)
Type of Staple :Corner, Double Stapling, Saddle Stitching
High Capacity Stacker-C1 (Primary & Secondary)
Tray :Output tray
Stacking system :Stacker tray (flattening and elevating)
Stacking orientation :  Stacked in the same way as output from the connected device
Paper Size :Output Tray: 13" x 19", 12" x 18", 11" x 17", LGL, LTR, LTRR, STMTR (304.8 x 457.2mm, 320 x 450mm, 330.2 x 482.6mm, A3, B4, A4, A4R, A5R, B5, B5R)
Stack Tray: 13" x 19", 12" x 18", 11" x 17", LGL, LTR, LTRR, 320 x 450mm,
330.2 x 482.6mm, A3, A4, B4, B5
Paper Weight: 64 to 300g/m²
Number of Pin:1
Mode   :Offset stacking for plots
Non-offset stacking
Stacking onto the output tray
Stacking Capacity :Output Tray 1,000 sheets (80g/m²)
Stack Tray :5,000 sheets (80g/m²)
Booklet Trimmer-C1
Margin Trimming :Open-End Only
Trim Thickness :20 sheets (80g/m²)
Waste Tray Capacity   :1,500 sheets of Trimmed Strip
Acceptable Paper Weight :64 to 300g/m²
Stacking Capacity :30 booklets (Letter / A4, 40 pages, 80g/m²), an equivalence of duplexed 2,400 pages
Perfect Binder-B1: (Requires Document Insertion Unit-C1)
Paper Weight:  Cover 90 to 300g/m²
Body : 64 to 163g/m²
Paper Size Cover :13" x 19", SRA3, 12" x 18", A3, 11" x 17", B4
Body : SRA4 (225mm x 320mm), LTR, A4, B5
Cutting Method
Size of Finished booklet         Width (Y)       Length (X)
- 3 direction trim         203mm to 297mm       138mm to 216mm
- 1 direction trim         257mm to 297mm       138mm to 216mm
- No trimming             257mm to 297mm       182mm to 216mm
Size of Cover
- 3 direction trim         + 13mm to + 79mm    + 49.5mm x 2 to 30.5mm
- 1 direction trim                     + 49.5mm x 2 to 30.5mm
- No trimming                         + 49.5mm x 2 to 30.5mm
Size of Body
- 3 direction trim         + 13mm to + 79mm    + 6.5mm to + 49.5mm
- 1 direction trim                     + 6.5mm to + 49.5mm
- No trimming
Binding Method :Perfect Binding
Trimming Method :     Stack rotation 3-direction or 1-direction. No trimming is possible
Booklet size: (after 3-direction trim) Width:             8" to 11 11/16" (203mm to 297mm)
Length: 5 ½" to 8 ½" (138mm to 216mm)
Trimming range Top / Bottom: 9/16" to 3 1/16" (13mm to 79mm)
Foredge: 5/16" to 1 15/16" (6.5mm to 49.5mm)
Body pages / Slip sheets
Number of sheets :64 to 80g/m² : 10 to 200 sheets: Thickness 25mm or less
81 to 105g/m² : 10 to 150 sheets: Thickness 25mm or less
106 to 163g/m² : 1 to 10 sheets: Slip sheets only
Sizes Width: 257mm to 320mm
Length: 182mm to 228.6mm, LTR, A4, B5, SRA4, 225mm to 320mm
Paper Weight : 64 to 163g/m²
Covers :Number of Sheets      1 sheet
Sizes Width: 257mm to 330.2mm
Length: 364mm to 487.7mm, SRA3, 225mm to 450mm, A3, 11" x 17", B4
Paper Weight: 90 to 300g/m²
Glue Capacity:380gm, enough for approximately 135 booklets when binding 100 pages booklets of A4 64g/m² paper
Document Insertion Unit-C1
Number of Trays :2
Capacity Upper Tray : 200 sheets
Lower Tray :200 sheets
Acceptable Paper Weight:64 to 300g/m²
Acceptable Paper Size :Upper Tray    LTR, LTRR, A4, A4R, B5, B5R
Lower Tray :13" x 19", 11" x 17", 12" x 18", LGL, LTR, LTRR, 450 x 320mm (SRA3), A3, B4, A4, A4R, B5, B5R
Tab Feeding Attachment-C1
Paper Size :LTR / A4
Paper Capacity :300 to 400 sheets (100g/m²) or 45mm in height
Paper Holder Size :270mm
Professional Paper Deck-A1
Pickup Method :Air Separation
Paper Cassette :Upper 1000 sheets (80g/m²)
Middle :1000 sheets (80g/m²)
Lower :2000 sheets (80g/m²)
Paper Type :Thin paper (64 to 79g/m²),
Plain paper: (80 to 105g/m²),
Recycled paper: (64 to 256g/m²),
Coloured paper :(64 to 79g/m²),
Thick paper :(106 to 300g/m²),
1-side coated paper :(80 to 300g/m²),
2-side coated paper :(80 to 300g/m²),
Transparency/film, Labeled paper, Postcard, Embossed paper, (80 to 300g/m²),
Vellum paper: (80 to 128g/m²),
Bond paper, Punched paper:(64 to 105g/m²),
Index paper :(151 to 209g/m²)
Feeding Speed :70ipm
Feeding Detection:Primary POD   Yes
Secondary POD :No


imagePRESS C6000 Server


 imagePRESS Server A1100, imagePRESS Server A2000 , imagePRESS Server A3000
Server Type:External ,External ,External
Processor: Intel Core2 Duo E6400 2.13GHz, Intel Pentium 4 3.2GHz (Dual Core) ,Dual Intel Xeon 3.0GHz (Dual Core)
Memory (DDR2) :1GB DDR2 Memory ,2GB DDR2 Memory,2GB DDR2 Memory
Hard Disk Drive :160GB SATA ,Dual 160GB SATA ,80GB, Dual 250GB SATA
Removable Hard Disk Drive
Optional
Optional Drive Network :DVD-R/W (CD-RW supported)
1000 Base-T / 100 Base-T / 10 Base-T
Basic Configuration : imagePRESS Server A1100, imagePRESS Server A2000, imagePRESS Server A3000
Graphic Arts Feature Set V2.0
Standard
Graphic Arts Package, Premium Edition V2.0 :Optional ,Optional, Standard
Hot Folders V2.0
Standard
Compose 2.0 : Optional          Optional          Standard
Impose 2.7 :    Optional          Standard         Standard
Graphic Use Interface Kit :Optional
Operator Maintenance :Standard
JDF Connector :Standard
Notes:
Graphic Art Feature Set V2.0 - TIFF-to-IT Converter (for Hot Folders), Paper Simulation, Software Calibration
Graphic Arts Package, Premium Edition V2.0 - Auto Trapping (Advanced type), Spot-On Version 2, Hot Folders Plug-in, Halftone simulation, White Spot Correction Function for “Paper Simulation", Progressive, Control Bar, ImageViewer 1.5, Postflight, Preflight
